Guardian

Key Features

  • Accurate Real-Time GPS Tracking Available 24/7 From Any Web Enabled Device Plus Mobile App For Android & iOS

  • Text Message And Email Alerts | Speed, Geo-Fence, Battery etc....

  • Up To 6 Months Of Backup Operation On Internal Rechargeable Battery

  • Powered By Easy To Use Google Maps Interface

  • Try Before You Buy! Call 317-662-4636 And Get A Demo Account Login And Free Live Software Training

  • $19.00 A Month | No Activation Fees | No Contracts | No Termination Fees

Additional Specifications

General

  • Communication Modes GPRS/EDGE/HSPA and CDMA 1xRTT packet data, UDP and SMS
  • Location Technology 50 channel GPS
  • Operating Voltage12 and 24 volt vehicle systems

GPS

  • Location TechnologyGPS; GLONASS, and QZSS capable
  • Enhancement TechnologySBAS: WAAS, EGNOS, MSAS
  • Receiver Type56 Channels
  • Location Accuracy2.0m
  • Location Update Rateup to 10 Hz
  • Tracking Sensitivity-162dBm
  • Acquisition Sensitivity-148dBm
  • Anti-jamming
  • AGPS/Location assistance capable

Cellular

  • Data SupportSMS, GPRS, CDMA 1xRTT or HSPA packet data
  • Operating Bands (MHz)
    • GSM/GPRS:
      • 850/900/1800/1900
    • CDMA/1XRTT:
      • 850/1900
    • HSPA/UMTS:
      • 800(VI)/850(V)/900(VII)/1700(IV)/1900(II)/2100(I)
  • Transmitter Power
    • GSM/GPRS:
      • 850/900/1800/1900
    • CDMA/1XRTT:
      • 1900
    • HSPA/UMTS:
      • All bands
  • HSPA Data Rates5.6 Mbps upload/7.2 Mbps download
  • HSPA FallbackEDGE/GPRS/GSM quad band
    EDGE MCS1-MCS9
    3GPP Release 6

Comprehensive I/O

  • Digital inputs1 fixed bias, 2 programmable bias
  • Digital outputs3 open collector (150mA)
  • Status LEDsGPS and cellular

Environmental

  • Temperature-30º to +85º C (operating); -30º to +85º C (storage)
  • Humidity95%RH @ 50º C non-condensing
  • Shock and VibrationSAE J1455
  • EMC/EMISAE J1113; FCC–Part 15B; Industry Canada
  • RoHS Compliant

Electrical

  • Operating Voltage9-32 VDC (startup, operating)
    7-32 VDC (momentary)
  • Power Consumption<1mA @ 12V (deep sleep)
    <16.7mA @ 12V (SMS only)
    <37mA @ 12V (SMS, data, and GPS)
    <75mA @ 12V (continuous transmit)
  • Back Up Battery3.7 Volt Lithium-Ion 5.2Ah
    6 hour charge time
    -15 degrees to +55 degrees C charging temperature

Physical

  • Dimensions2.125 x 4.33 x 1.59”, (54 x 110 x 40.4mm)
  • Weight8 oz, (226g)

Connectors, SIM Access

  • SIM Access Internal

Certifications

  • Fully certified FCC, CE, IC, PTCRB, applicable carriers

Mounting

  • Standard tie-wrap or adhesive
    Screw mounting bracket
You can access our easy to use tracking platform from any web enabled device! We also have applications for both Android and iOS.
