Sentry Specifications

Key Features

  • Accurate Real-Time GPS Tracking Available 24/7 From Any Web Enabled Device Plus Mobile App For Android & iOS

  • Text Message And Email Alerts | Speed, Geo-Fence, Battery etc....

  • Up To 2 Weeks Of Use With Built In Rechargeable Battery!

  • Powered By Easy To Use Google Maps Interface

  • Try Before You Buy! Call 317-662-4636 And Get A Demo Account Login And Free Live Software Training

  • $19.00 A Month | No Activation Fees | No Contracts | No Termination Fees

Additional Specifications

Frequency

Quad band: 850/900/1800/1900 MHz

Compliant to GSM phase 2/2+

Class 4 (2W @ 850/900 MHz)

Class 1 (1W @ 1800/1900 MHz)

GRPS

GRPS multi-slot class 12

GRPS mobile station class B

RMS Phase Error

5 Deg

Max Out RF Power

GSM850/GSM900:33.0+2dBm

DCS/PCS: 30.0+2dBm

Dynamic Input Range

-15~-108 dBm

Receiver Sensitivity

Class II RBER 2% (-107 dBm)

Stability Of Frequency

<2.5 ppm

Max Frequency Error

+0.1 ppm

General Specifications

Dimensions

6.85mm * 38.5mm * 23.5mm

Weight

60g

Battery

Li-polymer 1300 mAh, 3.7v

Standby Time

Without reporting : 400 hours

5 minutes reporting : 140 hours

10 minutes reporting : 180 hours

Water Resistance

IPX5 compliant

Charging Voltage

5V DC

External Battery Voltage

3.5v to 4.5V DC

Operating Temperature

-20°C ~ +55°C

You can access our easy to use tracking platform from any web enabled device! We also have applications for both Android and iOS.
